Switching Power Supply
Power Supply Unit is the electronic circuit used to provide energy for active components in electronic equipment. Certainly every electronic device using the Power Supply Unit.
Each active component in electronic equipment, require a different voltage and current, such as 5V, 3.3V, 12V etc. In carrying out their duties, this unit works very hard and usually result in excessive heat. This could damage...
Variable Power Supply 1.5V - 35V DC
IC = LM317 - P1 = 4,7KΩ - R = 120Ω
C1 = 100nF/63V - C2 = 1uF/35V - C3 = 10uF/35V - C4 = 2200uF/35V
D1-D4 = 1N4...
